Noble Metal Aerogels Enabled by Freezing: Multi-Scale Structured Materials for Electrocataly­sis and Photoelectro­catalysis

13.05.2020

TU Dresden chemists developed a freeze-thaw method, capable of synthesising various noble metal aerogels (NMAs) with clean surfaces and multiscale structure. In virtue of their hierarchical structures and unique optical properties, outstanding performance for electro-oxidation of ethanol is found. The research provides new ideas for designing various gel or foam materials for high-performance electrocatalysis and photoelectrocatalysis.

As a new class of porous materials, noble metal aerogels (NMAs) have drawn tremendous attention because of their combined features including self-supported architectures, high surface areas, and numerous optically and catalytically active sites, enabling their impressive performance in diverse fields.


Schematic presentation of the freeze-thaw method.

© Wiley-VCH


Dresden chemists crafted a novel freeze-thaw method by using the self-healing properties of noble metal gels and the ice-templating effect.

© Wiley-VCH

However, current fabrication methods suffer from long fabrication periods, unavoidable impurities, and uncontrolled multiscale structures, discouraging their fundamental and application-orientated studies.

Dr. Ran Du from China has been an Alexander von Humboldt research fellow at TU Dresden since 2017. In collaboration with the Dresden chemists Dr. Jan-Ole Joswig and Professor Alexander Eychmüller, they recently crafted a novel freeze-thaw method capable of acquiring various multi-scale structured noble metal aerogels as superior photoelectrocatalysts for electro-oxidation of ethanol, promoting the application for fuel cells.

Their work has now been published as cover story in the prestigious journal Angewandte Chemie International Edition.

Ran Du and his team have found unusual self-healing properties of noble metal gels in their previous works. Inspired by this fact, a freeze-thaw method was developed as an additive-free approach to directly destabilise various dilute metal nanoparticle solutions (concentration of 0.2-0.5 mM).

Upon freezing, large aggregates were generated due to the intensified salting-out effects incurred by the dramatically raised local solute concentration; meanwhile, they were shaped at micrometer scale by in situ formed ice crystals. After thawing, aggregates settled down and assembled to monolithic hydrogels as a result of their self-healing properties. Purified and dried, clean hydrogels and the corresponding aerogels were obtained.

Due to the hierarchically porous structures, the cleanliness, and the combined catalytic/optical properties, the resulting gold-palladium (Au-Pd) aerogels were found to display impressive light-driven photoelectrocatalytic performance, delivering a current density of up to 6.5 times higher than that of commercial palladium-on-carbon (Pd/C) for the ethanol oxidation reaction.

“The current work provides a new idea to create clean and hierarchically structured gel materials directly from dilute precursor solutions, and it should adapt to various material systems for enhanced application performance for catalysis and beyond”, assumes chemist Ran Du.

Media Enquiries:
Nicole Gierig
Public Relations Advisor
School of Science
TU Dresden
Email: Nicole.gierig@tu-dresden.de

Originalpublikation:

Du, R., Joswig, J.-O., Hübner, R., Zhou, L., Wei, W., Hu, Y., Eychmüller, A. (2020). Freeze-Thaw-Promoted Fabrication of Clean and Hierarchically-Structured Noble Metal Gels for Electrocatalysis and Photoelectrocatalysis. Angew. Chem. Int. Ed., DOI: 10.1002/anie.201916484.

Kim-Astrid Magister | Technische Universität Dresden
Further information:
https://tu-dresden.de/tu-dresden/newsportal/news/erst-einfrieren-dann-auftauen-neues-verfahren-zur-herstellung-von-edelmetallaerogelen-fuer-die-elektro-und-photoelektrokatalyse
