Ethernet switches permit flexible communication

20.07.2015
  • Cost-effective entry-level devices with wide range of functions
  • Ethernet switches permit communication via Profinet or EtherNet/IP
  • Suitable for flexible use in manufacturing industry, process industry, logistics, building management systems, and transportation

Siemens is expanding its range of managed Industrial Ethernet switches with a new product line. The cost-effective Layer 2 Scalance XB-200 switches provide high data rates up to 100 Mbps and a multitude of functions. They support, for example, both the Profinet standard and the EtherNet/IP standard. Users can choose between both standards using a switchover function.

As a result, the devices can be used for real-time communication in a variety of automation environments. The space-saving switches provide comprehensive functions for increasing safety and for configuration, diagnostics, and management of networks. Typical applications include machine networking in plants of the manufacturing industry and of the process industry such as oil and gas, pharmaceuticals, and chemicals. In addition, the switches can be used in logistics, building technology, and transportation.

The compact switches support VLANs (Virtual Local Area Networks) and are also certified for use in hazardous areas (IECEx/ATEX Zone 2/UL HazLoc). Security functions such as multicast blocking, loop detection and access control via Radius Server allow them to be integrated into security concepts for the protection of networks. Comprehensive SNMP (Simple Network Management Protocol) functions such as SNMP V3 allow the monitoring of large networks with monitoring tools such as Sinema Server.

The four device versions in a plastic enclosure with widths of 40 mm, 80 mm, or 120 mm save space in the control cabinet. With up to 16 electrical and three optical connections (SC, ST/SC, and SC LD), the devices offer great flexibility in choosing the right switch and can even cover distances up to 26 km in single mode. A new slide on the enclosure simplifies unlocking and allows easy manual installation of switches on the DIN rail.

Network communication is not interrupted even during a power failure due to the redundant power supply with two 3-pin connectors. The console port allows users to connect to a terminal for configuration, diagnostics, and management of the network using a CLI (command line interface). Alternatively, these settings can be made via the web interface of the Scalance XB-200.

A five-year warranty applies to the new Scalance XB-200, as for all Scalance products with delivery date January 1, 2015 or later.

Further information is available at www.siemens.com/x-200


Siemens AG (Berlin and Munich) is a global technology powerhouse that has stood for engineering excellence, innovation, quality, reliability and internationality for more than 165 years. The company is active in more than 200 countries, focusing on the areas of electrification, automation and digitalization. One of the world's largest producers of energy-efficient, resource-saving technologies, Siemens is No. 1 in offshore wind turbine construction, a leading supplier of combined cycle turbines for power generation, a major provider of power transmission solutions and a pioneer in infrastructure solutions as well as automation, drive and software solutions for industry. The company is also a leading provider of medical imaging equipment – such as computed tomography and magnetic resonance imaging systems – and a leader in laboratory diagnostics as well as clinical IT. In fiscal 2014, which ended on September 30, 2014, Siemens generated revenue from continuing operations of €71.9 billion and net income of €5.5 billion. At the end of September 2014, the company had around 343,000 employees worldwide on a continuing basis.

Further information is available on the Internet at www.siemens.com


Reference Number: PR2015070279PDEN


Contact
Mr. David Petry
Process Industries and Drives Division
Siemens AG

Schuhstr. 60

91052 Erlangen

Germany

Tel: +49 (9131) 7-26616

david.petry​​@siemens.com
